6034 2rs
YWS or OEM
Deep groove ball bearing
Deep groove ball bearing
YWS/OEM
170mm
260mm
6304 2rs
P0 P6 P5 P4 P2
2 rs
Single
Jinan
Chrome steel
170X260X42mm
Steel
Machinery
OEM
Long life
Product Details
6034 2rs deep groove ball bearing 170X260X42mm
product information:
Structure:deep groove ball bearing
Type:needle deep groove ball bearing
Brand Name:YWS
Internal diameter:170mm
External diameter:260mm
width：42mm
size:170X260X42mm
Weight: 6.5kg
Dynamic Load Capacity (Cr): 170000 N
Static Load Capacity (Cor): 170000 N
Material:Chrome steel/GCr15/Stainless steel/ceramic
Sealing type: You can choose Metal seal Or Rubber seal
Is customized: Yes (Drawings required)
Related accessories: Oil seal,Circlip and housings etc.
Wholesale and freight: To provide you with accurate solutions
Product description：
Deep groove geometry for high speeds and supporting both radial and axial loads
Chrome steel for durability and resistance to deformity under heavy loads
Rubber seals on both sides of the bearing to keep lubricant in and contaminants out
Lubricated at manufacturer for no additional lubrication required
Suitable for use in electric motor applications
The Application:
6034 bearing could be used in vulcanizing machine, molding machine accessories, mine construction equipment, mixing equipment, high frequency welding machine, diagnostic equipment, household sewing machines, workbench, binding machine, cooling tower, etc.
The 6000 series deep groove ball bearing models and sizes:
| Models | ID mm | OD mm | Width mm | Rsmin mm | Cr N | Cor N | Weight (kg) |
| 603 | 3 | 9 | 3 | 0.2 | 486 | 223 | 0.0014 |
| 604 | 4 | 12 | 4 | 0.2 | 960 | 350 | 0.0023 |
| 605 | 5 | 14 | 5 | 0.2 | 1070 | 420 | 0.0037 |
| 606 | 6 | 17 | 6 | 0.3 | 1960 | 730 | 0.0069 |
| 607 | 7 | 19 | 6 | 0.3 | 2800 | 1060 | 0.0082 |
| 608 | 8 | 22 | 7 | 0.3 | 3290 | 1360 | 0.0129 |
| 609 | 9 | 24 | 7 | 0.3 | 3330 | 1410 | 0.016 |
| 6000 | 10 | 26 | 8 | 0.3 | 4160 | 1780 | 0.019 |
| 6001 | 12 | 28 | 8 | 0.3 | 5110 | 2380 | 0.022 |
| 6002 | 15 | 32 | 9 | 0.3 | 5590 | 2840 | 0.03 |
| 6003 | 17 | 35 | 10 | 0.3 | 6000 | 3250 | 0.039 |
| 6004 | 20 | 42 | 12 | 0.6 | 9390 | 5020 | 0.069 |
| 6005 | 25 | 47 | 12 | 0.6 | 10060 | 5860 | 0.08 |
| 6006 | 30 | 55 | 13 | 1 | 11900 | 7460 | 0.116 |
| 6007 | 35 | 62 | 14 | 1 | 16210 | 10420 | 0.155 |
| 6008 | 40 | 68 | 15 | 1 | 17030 | 11700 | 0.192 |
| 6009 | 45 | 75 | 16 | 1 | 21080 | 14780 | 0.245 |
| 6010 | 50 | 80 | 16 | 1 | 22000 | 16260 | 0.261 |
| 6011 | 55 | 90 | 18 | 1.1 | 31500 | 18400 | 0.384 |
| 6012 | 60 | 95 | 18 | 1.1 | 30000 | 23000 | 0.426 |
| 6013 | 65 | 100 | 18 | 1.1 | 32000 | 25000 | 0.428 |
| 6014 | 70 | 110 | 20 | 1.1 | 38000 | 31000 | 0.62 |
| 6015 | 75 | 115 | 20 | 1.1 | 38000 | 31000 | 0.63 |
| 6016 | 80 | 125 | 22 | 1.1 | 47500 | 40000 | 0.86 |
| 6017 | 85 | 130 | 22 | 1.1 | 47500 | 40000 | 0.935 |
| 6018 | 90 | 140 | 24 | 1.5 | 63800 | 59000 | 1.38 |
| 6019 | 95 | 145 | 24 | 1.5 | 66700 | 62300 | 1.5 |
| 6020 | 100 | 150 | 24 | 1.5 | 72500 | 70000 | 1.63 |
| 6022 | 110 | 170 | 28 | 2 | 80000 | 78900 | 2.35 |
| 6024 | 120 | 180 | 28 | 2 | 81000 | 81000 | 2.62 |
| 6026 | 130 | 200 | 33 | 2 | 96800 | 100000 | 3.55 |
| 6028 | 140 | 210 | 33 | 2 | 123700 | 130000 | 4.21 |
| 6030 | 150 | 225 | 35 | 2.1 | 132000 | 125000 | 4.9 |
| 6032 | 160 | 245 | 38 | 2.1 | 145000 | 138000 | 5.89 |
| 6034 | 170 | 260 | 42 | 2.1 | 170000 | 170000 | 6.5 |
| 6036 | 180 | 280 | 46 | 2.1 | 188000 | 198000 | 8.51 |
| 6038 | 190 | 290 | 46 | 2.1 | 188000 | 200000 | 8.86 |
| 6040 | 200 | 310 | 51 | 2.1 | 205000 | 225000 | 11.64 |
| 6044 | 220 | 340 | 56 | 3 | 252000 | 268000 | 18 |
| 6048 | 240 | 360 | 56 | 3 | 270000 | 292000 | 20 |
| 6052 | 260 | 400 | 65 | 4 | 292000 | 372000 | 28.2 |
| 6056 | 280 | 420 | 65 | 4 | 305000 | 408000 | 32.1 |
Sincerely welcome to send enquiry to us!!!
