Deep groove ball bearing
6000 series
YWS/OEM
15mm
35mm
6202 2rs
2RS
Single
China
Chrome steel
15x35x11mm
Steel
Machinery
OEM
Long life, high precision
Product Details
6202 RS deep groove ball bearing 15X35X11mm
Data Sheet
Internal diameter:15mm
External diameter:35mm
Width:11mm
Load Rating(Cor):3700 N
Load Rating(Cr):7450 N
Weight:0.045kg
Application
6202 bearing is mainly used in hydroelectric generators, vertical motors, Marine propeller shaft, rolling mill rolling screw reducer, tower crane, grinding machine, extrusion machine, forming machine.
The 6200 series deep groove ball bearing models and sizes:
| Models | ID mm | OD mm | Width mm | Rsmin mm | Cr N | Cor N | Weight (kg) |
| 623 | 3 | 10 | 4 | 0.15 | 640 | 220 | 0.0016 |
| 624 | 4 | 13 | 5 | 0.2 | 1150 | 400 | 0.0032 |
| 625 | 5 | 16 | 5 | 0.3 | 1880 | 680 | 0.0051 |
| 626 | 6 | 19 | 6 | 0.3 | 2800 | 1060 | 0.0086 |
| 627 | 7 | 22 | 7 | 0.3 | 3290 | 1360 | 0.0131 |
| 628 | 8 | 24 | 8 | 0.3 | 3330 | 1410 | 0.017 |
| 629 | 9 | 26 | 8 | 0.3 | 4160 | 1780 | 0.0191 |
| 6200 | 10 | 30 | 9 | 0.6 | 5110 | 2380 | 0.032 |
| 6201 | 12 | 32 | 10 | 0.6 | 6180 | 3060 | 0.037 |
| 6202 | 15 | 35 | 11 | 0.6 | 7450 | 3700 | 0.045 |
| 6203 | 17 | 40 | 12 | 0.6 | 9560 | 4780 | 0.065 |
| 6204 | 20 | 47 | 14 | 1 | 12840 | 6650 | 0.106 |
| 6205 | 25 | 52 | 15 | 1 | 14020 | 7930 | 0.128 |
| 6206 | 30 | 62 | 16 | 1 | 19460 | 11310 | 0.199 |
| 6207 | 35 | 72 | 17 | 1.1 | 25670 | 15300 | 0.288 |
| 6208 | 40 | 80 | 18 | 1.1 | 29520 | 18140 | 0.366 |
| 6209 | 45 | 85 | 19 | 1.1 | 32500 | 20400 | 0.416 |
| 6210 | 50 | 90 | 20 | 1.1 | 35000 | 23200 | 0.462 |
| 6211 | 55 | 100 | 21 | 1.5 | 43500 | 29200 | 0.602 |
| 6212 | 60 | 110 | 22 | 1.5 | 52500 | 36000 | 0.804 |
| 6213 | 65 | 120 | 23 | 1.5 | 57200 | 40100 | 0.99 |
| 6214 | 70 | 125 | 24 | 1.5 | 62000 | 44000 | 1.07 |
| 6215 | 75 | 130 | 25 | 1.5 | 66000 | 49500 | 1.18 |
| 6216 | 80 | 140 | 26 | 2 | 72500 | 53000 | 1.4 |
| 6217 | 85 | 150 | 28 | 2 | 83500 | 64000 | 1.79 |
| 6218 | 90 | 160 | 30 | 2 | 96000 | 71500 | 2.15 |
| 6219 | 95 | 170 | 32 | 2.1 | 109000 | 82000 | 2.62 |
| 6220 | 100 | 180 | 34 | 2.1 | 122000 | 93000 | 3.14 |
| 6221 | 105 | 190 | 36 | 2.1 | 133000 | 104000 | 3.66 |
| 6222 | 110 | 215 | 38 | 2.1 | 144000 | 117000 | 4.44 |
| 6224 | 120 | 220 | 40 | 2.1 | 145000 | 118000 | 5.11 |
| 6226 | 130 | 230 | 40 | 3 | 167000 | 146000 | 5.82 |
| 6228 | 140 | 250 | 42 | 3 | 166000 | 150000 | 7.47 |
| 6230 | 150 | 270 | 45 | 3 | 176000 | 168000 | 9.41 |
| 6232 | 160 | 290 | 48 | 3 | 185000 | 186000 | 15 |
| 6234 | 170 | 310 | 52 | 4 | 212000 | 224000 | 16.5 |
| 6236 | 180 | 320 | 52 | 4 | 256000 | 279000 | 17.8 |
| 6238 | 190 | 340 | 55 | 4 | 265000 | 320000 | 23 |
| 6240 | 200 | 360 | 58 | 4 | 288000 | 335000 | 24.8 |
| 6244 | 220 | 400 | 65 | 4 | 297000 | 365000 | 36.5 |
| 6248 | 240 | 440 | 72 | 4 | 360000 | 470000 | 53.9 |
