6203DDU deep groove ball bearing 17X40X12mm

6203DDU deep groove ball bearing 17X40X12mm

product information:

Structure:Deep Groove

Type:Ball, ball bearing

Brand Name:YWS

Internal diameter:17mm

External diameter:40mm

Width:12mm

size:17X40X12mm

weight：0.065kg

Static Load Capacity：4800  newtons

Dynamic Load Capacity：9550  newtons

Material:Chrome steel/GCr15/Stainless steel/ceramic

Sealing type: You can choose Metal seal Or Rubber seal

Is customized: Yes (Drawings required)

Related accessories: Oil seal,Circlip and housings etc.

Wholesale and freight: To provide you with accurate solutions

Product description：

This 6203 ball bearing is made of chrome steel, is double sealed, and has C3 internal clearance. It has a 17 mm inside diameter, a 40 mm outside diameter, and a 12 mm depth. This single-row ball bearing has deep groove geometry for applications that require high speeds and support both radial and axial loads. This bearing is made of chrome steel for durability and resistance to deformity under heavy loads. It has C3 radial internal clearance for radial slack between the inner and outer rings is greater than CN (normal) to compensate for thermal expansion. Rubber seals on both sides of the bearing keep the lubricant in and contaminants out. The static load rating is 4,800 newtons and the dynamic load rating is 9,550 newtons. A steel cage spaces the balls for even load distribution and prevents contact to reduce friction, vibration, and noise. The maximum speed with grease lubrication is 12,000 revolutions per minute (rpm). This deep groove ball bearing is suitable for use in applications such as transmissions, motors, and pumps.

Product features：

Single-row deep groove geometry for high speeds and supporting both radial and axial loads

Chrome steel for durability and resistance to deformity under heavy loads

C3 radial internal clearance for radial slack between the inner and outer rings is greater than CN (normal) to compensate for thermal expansion

Rubber seals on both sides of the bearing keep the lubricant in and contaminants out

Static load rating of 4,800 newtons and dynamic load rating of 9,550 newtons

The Application:

The DDU bearing mainly used in mining surveying instrument, coating production line, hardness tester, plastic granulator, compaction machinery, sewage pump, coking equipment, gear shaper, energy-saving welding machine, chain hoist, submersible mixer, etc.
