End support with ball bearing for CNC Router Milling machine

Ball screw support unit is a bearing connected ball screw and motor ,its structure and specialty for standard ball spiral its axis of the inventory the finished product, preparation of the standardization of the support unit EK, EF type, to general ball spiral poles prepared the standard support unit BK, BF type.

Support unit EK, BK type of internal bearing load in the right amount of lithium base grease, with the special seal gasket to seal, can direct installation, use for a long time.

Support unit application:
support Bearing  is widely used in precision screw machine tools, electronics, automation, textile
automotive,medical, food, packaging, rubber and other fields.

Products include,  ball splines, linear combination of components such as bearings and
related linear motion products

Smooth Operation

The high efficiency of ball screws is vastly superior to conventional screws. The torque required is less than 30%. Linear motion can be easily changed from rotary motion.

High Rigidity and Preload

When axial play is minimized in conventional screw-nut assemblies, the actuating torque becomes excessive and the operation is not smooth. The axial play in TBI MOTION or ERSK precision ball screws may be reduced to zero by preloading and a light smooth operation is still possible. herefore, both low torque and high rigidity can be obtained simultaneously.TBI MOTION or ERSK ball screws have gothic arch groove profiles which allow these conditions to be achieved.

Circulation Method

Ball return tube method.(V,E,S,Y type);Ball defelector method.(I,U,M,K type)

High Durability

Rigidly selected materials, intensive heat treating and processing techniques, backed by years of experience,have resulted in the most durable ball screws manufactured.

Feature

1. Space saving nternal circulate design

2. Low friction force with 1/3 over acme screw

3. Ensure for high accuracies

4. Micro feed with tolerance within in 0.1μm

5. Zero backlash, high stiffness.

Application

For delicate application in industrial application, machine tool and automation application.
