697 2rs
YWS or OEM
OEM Customized Services
Product Details
FRONT BEARINGS WITH ceramic BALLS 7x17x5 zro2 ball bearing 697 2rs
product information:
Structure:Deep Groove
Type:Ball, ball bearing
Brand Name:YWS
Internal diameter:7mm
External diameter:17mm
Width:5mm
size:7x17x5
Material:Chrome steel/GCr15/Stainless steel/ceramic
Sealing type: You can choose Metal seal Or Rubber seal
Is customized: Yes (Drawings required)
Related accessories: Oil seal,Circlip and housings etc.
Wholesale and freight: To provide you with accurate solutions
product features：
Corrosion resistance.High temperature resistance.Electrical insulation (except SiC).
Non magnetic field High stiffness.Small proportion ETC.Hybrid ceramic ball bearing can used in
high-speed .harsh condition and Low lubrication.and it can help reduce wear, noise, and vibration.
To Make maintenance easier,Thus, the longer life of the bearing is achieved, and its performance
and reliability are greatly improved.
Bearing no. | Inner Ring | Outer Ring | Width | Cr(N) | Cor(N) | Speed(1000r/min) | |
| (d) | (D) | (H) | Grease | Oil | |||
| 623 | 3 | 10 | 4 | 631 | 219 | 50 | 60 |
| 624 | 4 | 13 | 5 | 1301 | 488 | 40 | 48 |
| 625 | 5 | 16 | 5 | 1729 | 675 | 36 | 43 |
| 626 | 5 | 19 | 6 | 2336 | 896 | 32 | 40 |
| 627 | 7 | 22 | 7 | 3287 | 1379 | 30 | 36 |
| 628 | 8 | 24 | 8 | 3333 | 1423 | 28 | 34 |
| 629 | 9 | 26 | 8 | 4575 | 1983 | 28 | 34 |
| 6200 | 10 | 30 | 9 | 5100 | 2390 | 24 | 30 |
| 6201 | 12 | 32 | 10 | 6800 | 3050 | 22 | 28 |
| 6202 | 15 | 35 | 11 | 7650 | 3750 | 20 | 24 |
| 6203 | 17 | 40 | 12 | 9550 | 4800 | 17 | 20 |
| 6204 | 20 | 47 | 14 | 12800 | 6650 | 15 | 18 |
| 6205 | 25 | 52 | 15 | 14000 | 7850 | 13 | 16 |
| 6206 | 30 | 62 | 16 | 19500 | 11300 | 12 | 14 |
| 6207 | 35 | 72 | 17 | 25700 | 15300 | 10 | 12 |
| 6208 | 40 | 80 | 18 | 29100 | 17800 | 0.88 | 10 |
| 6209 | 45 | 85 | 19 | 32500 | 20400 | 0.72 | 0.9 |
| 6210 | 50 | 90 | 20 | 35000 | 23200 | 0.65 | 0.8 |
| Yuki Bearing Features |
| ISO9001:2008 quality management systemPrecision: ABEC-1(P0), ABEC-3(P6), ABEC-5(P5), ABEC-7(P4)Noise level: Z1, Z2, Z3, Z4Vibration Level: V1, V2, V3, V4Clearance: C2, C3, C4, C5Hardness: 59-63 HRCLow friction, long service lifeWelcome OEM order |
Sincerely welcome you to send enquiry to us!!!
