SL182948
YWS or OEM
OEM Customized Services
Product Details
product information:
Structure:cylindrical roller bearing
Type:cylindrical roller bearing
Brand Name:YWS
Internal diameter:240mm
External diameter:320mm
Width:48mm
size:240×320×48mm
Maximum Rotational Speed:1200 rpm
Static Load Capacity:255000 pounds
Dynamic Load Capacity:135000 pounds
Material:Chrome steel/GCr15/Stainless steel/ceramic/ZrO2
Is customized: Yes (Drawings required)
Wholesale and freight: To provide you with accurate solutions
Tips: Please contact us for details of the required products.
Product description：
This cylindrical roller bearing with a removable outer ring is suitable for applications that support high radial loads. This roller bearing has a CN (normal) radial clearance for applications and operating conditions with normal shaft and housing tolerances where thermal expansion is not a factor. This is a single row roller bearing that supports high radial loads with low friction. A removable outer ring in the open bearing allows application of lubrication. This roller bearing is measured in metric units for industry cross-matching and parts consistency.
Cylindrical roller bearings are used in applications where high radial loads are present such as in conveyer belts, traction motors, railway car axle boxes, and oilfield mud pumps, among others.
Product features：
cylindrical roller bearing with a removable outer ring suitable for high radial loads
CN (normal) radial clearance for applications where thermal expansion is not a factor
Single row roller bearing for high radial loads with low friction
Removable outer ring in open bearing allows for lubrication in place
Metric unit measurements for industry consistency
| Cylindrical Roller Bearings | |
| Double row | SL0148 Bore 150-400mm |
| SL0149 Bore 60-400mm | |
| SL0249 Bore 150-400mm | |
| SL0249 Bore 60-400mm | |
| Double row with seals | SL04...PP Bore 130-300mm |
| SL0450...PP 20-300mm | |
| Single row | SL1818 Bore 200-500mm |
| SL1822 Bore 20-200mm | |
| SL1829 Bore 60-500mm | |
| SL1830 Bore 20-380mm | |
| SL1850 Bore 20-380mm | |
| SL1923 Bore 25-260mm | |
10.6 Design Equivalent Dimension(mm) MASS(KG) d D B NCF3040V SL183040 200 310 82 21.8 NCF2240V SL182240 200 360 98 43.12 NCF1844V SL181844 220 270 24 2.8 NCF2944V SL182944 220 300 48 9.9 NCF3044V SL183044 220 340 90 28.4 NCF1848V SL181848 240 300 28 4.4 NCF2948V SL182948 240 320 48 10.6 NCF3048V SL183048 240 360 92 30.9 NCF1852V SL181852 260 320 28 4.71 NCF2952V SL182952 260 360 60 18.5 NCF3052V SL183052 260 400 104 44.5 NCF1856V SL181856 280 350 33 7 NCF2956V SL182956 280 380 60 19.7 NCF3056V SL183056 280 420 106 48 NCF1860V SL181860 300 380 38 10 NCF2960V SL182960 300 420 72 31.2 NCF3060V SL183060 300 460 118 66.6 NCF1864V SL181864 320 400 38
